DSEM870 | 7″ Programmable Display
- Capacitive touchscreen (M870-02 variant)
- 512 MB of DDR3 SDRAM and 2 GB of NAND mass storage.
- 4 configurable inputs, 4 configurable digital outputs
- Ethernet interface for communications.
- Flexible user programming via CODESYS 3.5 or Qt.
- 2 camera inputs.
PRODUCT VARIANTS
M870-01 – CODESYS (Standard)
M870-02 – CODESYS (Touchscreen)
M870-03 – CODESYS (Standard with WebVisu)
Call for Quote for international purchases!
$3,811.16
Compare
SKU: M870-01
Categories: Vehicle & Off-Highway Machinery (M-Series)
The DSEM870 is a 7” programmable display designed for use on vehicles and off highway machinery. Developed for use as a standalone product or with the DSEM640 programmable controller, the DSEM870 provides users with outstanding flexibility.
The DSEM870 is configured using CODESYS 3.5 (M870-01 / M870-02 / M870-03)
OVERALL SIZE
272 mm x 165 mm x 81 mm / 10.7 ” x 6.5 ” x 3.2 ”WEIGHT
1.25 kg
2.76 lbCUT-OUT
231 mm x 133 mm (R 12 mm) / 9.1” x 5.24” (R 0.5”)
Additional information
| BRANDS | DSE |
|---|
