DSEA106 MKII | Digital Automatic Voltage Regulator (AVR)
- Soft start ramping.
- Under frequency roll off protection with optional instantaneous step.
- Remote voltage adjustment using -10 V to 10 V signal and 5kΩ potentiometer.
- Remote voltage adjustment potentiometer open circuit protection.
- LED Indication for fault and operating status.
- DIP Switch selection.
PRODUCT VARIANTS
A106-02 – A106 Digital AVR (AUX)
Call for Quote for international purchases!
$437.99
Compare
SKU: A106-02
Categories: AVR | DSE, Main Protection Relay
The DSEA106 MKII Digital Automatic Voltage Regulator (AVR) builds on the success of the DSEA106 product providing additional features to enhance customer applications. The product regulates the output voltage of an AC alternator and is supplied by a stator auxiliary winding or a shunt system taking power from the output windings.
The product provides higher levels of stability compared to analogue designs by maintaining a smooth, stable and regulated AC output voltage that is unaffected by the connected electrical load.
OVERALL SIZE
179 mm x 108 mm x 61 mm (7.1” x 4.3” x 2.4”)
Additional information
| BRANDS | DSE |
|---|
