DSE6110 MKIII | Auto Start Control Module
- 6 configurable DC outputs.
- 4 configurable analogue/digital inputs.
- 8 configurable digital inputs.
- DSENet expansion compatibility.
- Support for 0-10 V & 4-20mA oil pressure senders.
- Generator/load current monitoring & protection.
- Fuel usage monitor and low level alarms.
PRODUCT VARIANTS
6110-05 – 6110 MKIII Auto Start Control Module (gasket not included)
6110-35 – Genset 6110 MKIII Auto Start Control Module (CC)
Call for Quote for international purchases!
$528.99
The DSE6110 MKIII is a auto start control module and the DSE6120 MKIII is a auto mains (utility) failure control module suitable for a wide variety of single, diesel or gas, gen-set applications. Monitoring an extensive number of engine parameters, the modules will display warnings, shutdown and engine status information on the back-lit LCD screen.The DSE6120 MKIII will also monitor the mains (utility) supply. The modules include a USB port as well as dedicated DSENet® terminals for system expansion.
Both modules are compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offer an extensive number of flexible inputs, outputs and engine protections so the system can be easily adapted to meet the most demanding industry requirements. The comprehensive list of features includes enhanced event and performance monitoring and PLC functionality. The modules can be easily configured using the DSE Configuration Suite PC software. Selected front panel editing is also available.
221 mm x 163 mm x 42.5 mm / 8.70 ” x 6.43 ” x 1.67 ”
PANEL CUTOUT SIZE
184 mm x 137 mm / 7.24 ” x 5.39 ”
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
0.5kg
Additional information
| Weight | 1.1 oz |
|---|---|
| Dimensions | 12 × 9 × 4 in |
| BRANDS | DSE |
