DSE8620 | Synchronising & Load Sharing Control Module
- Type 1 fully flexible inputs.
- Configurable inputs/outputs (12/8).
- Remote communications (RS232, RS485, Ethernet).
- Direct governor control.
- DSE Configuration Suite PC Software.
- Battery charger support across DSENet®.
- Configurable CAN transmit and receive.
- Can be configured for use as a DSE8610 MKII.
PRODUCT VARIANTS
8620-01 – 8620 Auto Mains (Utility) Failure Control Module
Call for Quote for international purchases!
$2,400.99
The DSE8620 MKII represents the latest in complex load sharing & synchronising control technology. Designed to synchronise a single genset with a mains (utility) supply, the DSE8620 MKII control module is packed with multiple features and benefits that are unrivalled across the generator control industry.
The controller also has the option to be configured for use as a DSE8610 MKII Auto Start Load Sharing & Synchronising Control Module. When converted for use as a DSE8610 MKII the unit provides generator to generator load share functionality.
OVERALL SIZE
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")
WEIGHT
0.88kg
Additional information
| Weight | 2.2 oz |
|---|---|
| Dimensions | 12 × 9 × 4 in |
| BRANDS | DSE |
