Only Transfer Switch 3 pole | 150 Amps | TS3P150
- Manufactured using UL 94V-0 plastics.
- Electrically operated and mechanically held.
- Coil operating voltage: 110 / 220 Vac +/- 20%.
- Monitor Normal & Standby source OV and UV.
- Compact size, light weight and low power consumption.
- Adjustable time delay in OFF position when transferring.
- Designed for cell-phone repeaters, and many industrial and home ATS applications.
- Electrically or manually operated, mechanically held contacts – (Open Transition) with adjustable time in neutral.
$702.90
International orders welcome! Call or email for shipping estimate
The TS3P150 is a 3-pole, 150-Amp transfer switch mechanism, sold as the switch body only without integrated controller or enclosure. It is designed for installation with a separate transfer switch controller in cell-phone repeater, industrial, and residential power transfer applications.
The switch is rated at 600V AC at 50/60 Hz, with a double-throw switch type and ATS Class PC classification. Transfer current is 2.0A at 220V AC. Remote start contactor capacity is 6A at 277V AC maximum. Normal and emergency ON contactor capacity is 7A at 250V AC maximum. Operation life is over 6,000 switching cycles with load.
Operating temperature range is -10°C to +70°C.
Additional information
| BRANDS | Mcpherson Controls |
|---|
