DSE2130 | Input Expansion Module
- DIN rail & chassis mount.
- Power on/link lost LED.
- 1.2km (0.75 Mile) working range.
- Connect maximum of 4 x DSE2130’s to a single host controller.
- Rotary ID switch to select address of DSE2130 to talk with host module when multiple DSE2130 modules are in use.
- Max of 32 digital inputs – 16 can be configured for use as analogue.
PRODUCT VARIANTS
2130-00 – 2130 Input Expansion Module
2130-00 – 2130 Input Expansion Module
Call for Quote for international purchases!
$331.99
1 in stock
SKU: 2130-00
Categories: Expansion Modules
The DSE2130 DSENet® Input Expansion Module has been developed for use with DSE modules. The DSE2130 extends the host modules input capabilities for increased application flexibility. This is achieved by providing an additional 8 inputs, consisting of 4 analogue inputs (can be configured as digital) and 4 digital inputs.
For enhanced communication with the host module, the DSE2130 features a DSENet® port for connection to DSE modules. A red status LED is provided to easily identify when the DSE2130 is connected to a power source and communicating with the host controller.
OVERALL SIZE
134 mm x 76 mm x 49 mm (5.3” x 3.0” x 1.9”)
WEIGHT
0.18kg
Additional information
| Weight | 0.9 oz |
|---|---|
| Dimensions | 8 × 8 × 4 in |
| BRANDS | DSE |
