DSE8660 MKII | Auto Transfer Switch & Mains (Utility) Control Module
- Display sets on load on modules LCD display.
- Multiple mains (utility) capability (with additional module).
- Sequential set start.
- Configurable inputs/outputs (12/8).
- Data logging (USB Memory Stick).
- DSE Configuration Suite PC Software.
- Tier 4 CAN engine support.
PRODUCT VARIANTS
8660-02 – 8660 MKII Auto Transfer Switch & Mains (Utility) Control Module (Ct, Rtc)
Call for Quote for international purchases!
$1,798.93
Compare
SKU: 8660-02
Categories: Load Sharing & Synchronizing
The DSE8660 MKII is the latest and most advanced Auto Transfer Switch & Mains (Utility) Control Module within the DSE synchronising and load sharing control module range. Developed alongside the DSE8610 MKII this control module provides industry-leading features and benefits for the most complex grid type generator installations.
OVERALL SIZE
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")
WEIGHT
0.88kg
Additional information
| BRANDS | DSE |
|---|
