DSE2131 | Ratiometric Input Expansion Module
- DIN rail & chassis mount.
- Power on/link lost LED.
- 1.2km (0.75 Mile) working range.
- Connect maximum of 4 x DSE2131’s to a single host controller.
- Rotary ID switch to select address of DSE2131 to talk with host module when multiple DSE2131 modules are in use.
- Max of 40 configurable inputs.
PRODUCT VARIANTS
2131-01 – 2131 Ratiometric Input Expansion Module
2131-01 – 2131 Ratiometric Input Expansion Module
Call for Quote for international purchases!
$305.99
Compare
SKU: 2131-01
Categories: Expansion Modules
The DSE2131 is a ratiometric input expansion module providing 10 additional inputs to the control module. Up to 4 x DSE2131 modules can be linked together to provide up to 40 additional inputs.
Designed to give greater input flexibility for meeting complex industry generator control specifications.
Inputs can be configured to connect to resistive sensors, 0-10 V DC signals or 4-20mA signals, analogue inputs. All configurations are controlled from within the host control module.
OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
WEIGHT
0.22kg
Additional information
| BRANDS | DSE |
|---|
