DSE335 | Auto Transfer Switch Control Module
- 415 V AC S1/S2 sensing for full 600 V
- Configurable Inputs (12)
- Configurable volt-free outputs (6)
- Configurable DC outputs (6)
- Bi-colour front panel LEDs
- 4-line back-lit LCD text display
- Remote monitoring.
- Supports multiple technologies
PRODUCT VARIANTS
0335-01 – 335 Auto Transfer Switch Control Module – 12/24 Volt DC Supply (includes gasket)
0335-01 – 335 Auto Transfer Switch Control Module – 12/24 Volt DC Supply (includes gasket)
Call for Quote for international purchases!
$836.21
Compare
SKU: 0335-01
Categories: Auto Transfer Switch
The DSE335 MKII is an automatic transfer switch controller designed to monitor the voltage and frequency of incoming AC supplies from two different sources. These are either generator or mains (utility), or a combination of both. The module monitors S1 (source 1) and in the event of a failure issues a start command to S2 (source 2). Various timing sequences are available to prevent nuisance starting on minor supply breaks.
The module is configured using the DSE Configuration Suite PC Software. Selected front panel editing is also available. Configurable inputs and outputs make the DSE335 MKII fully flexible to suit a wide variety of applications.
OVERALL SIZE
250 mm x 189 mm x 50.5 mm / 9.85 ” x 7.43 ” x 1.99 ”
PANEL CUT-OUT
220 mm x 160 mm (8.66 ” x 6.30 ”)
MAXIMUM PANEL THICKNESS
8 mm (0.3”)
WEIGHT
0.9kg
0.9kg
Additional information
| Weight | 2 oz |
|---|---|
| Dimensions | 12 × 9 × 4 in |
| BRANDS | DSE |
