DSE2133 | RTD/Thermocouple Input Expansion Module
- Power on/link lost LED.
- 1.2km (0.75 Mile) working range.
- Connect maximum of 4 x DSE2133’s to a single host controller.
- Rotary ID switch to select address of DSE2133 to talk with host module when multiple DSE2133 modules are in use.
- Max of 32 RTD/thermocouple inputs.
- Compatible with J-type and K-type thermocouple, PT 100 and 3 wire RTD sensors.
PRODUCT VARIANTS
2133-01 – 2133 RTD/Thermocouple Input Expansion Module
2133-01 – 2133 RTD/Thermocouple Input Expansion Module
Call for Quote for international purchases!
$368.99
Compare
SKU: 2133-01
Categories: Expansion Modules
The DSE2133 is an RTD/thermocouple input expansion module providing 8 additional inputs to the control module. Up to 4 DSE2133 modules can be linked together to provide up to 32 additional inputs.
Designed to give greater input flexibility for meeting complex industry generator control specifications.
Inputs can be configured as RTD or thermocouple and are controlled from within the host control module.
OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
WEIGHT
0.22kg
Additional information
| BRANDS | DSE |
|---|
