DSE6120 MKIII | Auto Mains Failure Control Module
- 6 configurable DC outputs.
- 4 configurable analogue/digital inputs.
- 8 configurable digital inputs.
- DSENet expansion compatibility.
- Support for 0-10 V & 4-20mA oil pressure senders.
RODUCT VARIANTS
6120-05 – 6110 MKIII Auto Mains (Utility) Failure Control Module
Call for Quote for international purchases!
$515.99
Compare
SKU: 6120-05
Categories: Auto Mains Failure
The DSE6120 MKIII is an Auto Mains (Utility) Failure Control Module suitable for a wide variety of single, diesel or gas, genset applications.
Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs and remote PC.
The module is compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offers an extensive number of flexible inputs, outputs and extensive engine protections so the system can be easily adapted to meet the most demanding industry requirements.
OVERALL SIZE
216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.5”)
PANEL CUTOUT SIZE
184 mm x 137 mm (7.2” x 5.3”)
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.5kg
216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.5”)
PANEL CUTOUT SIZE
184 mm x 137 mm (7.2” x 5.3”)
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.5kg
Additional information
| Weight | 1.8 oz |
|---|---|
| Dimensions | 12 × 9 × 4 in |
| BRANDS | DSE |
