Mecc Alte | Ducati Energia 35µF Capacitor | P/N 416.30.A1.80 | 9910303127

Ducati Energia 35µF Capacitor, P/N 416.30.A1.80 | 9910303127, 550V AC, 3.3 kVAr, 50/60Hz, Double FASTON, Metal Case, Floppy Cap Series, for Mecc Alte Generators

The capacitors making up the FLOPPY CAP series are housed in metal cases. The lids are made of self-extinguishing plastic (Class V2 under the inflammability classification of standard UL 94). The capacitor is sealed closed by reading the case over the lid, a solution that guarantees perfect airtightness, which is necessary to ensure the efficiency of the over-pressure safety device. The placement of an insulating container between the capacitor element and the metal case, combined with the embedding of the capacitor element in resin, makes the capacitor extremely safe from an electrical point of view (ground insulation) and insensitive to vibrations.

• Dimensions: the catalog says 60 x 137 mm. The Google summary’s 55 x 132 mm belongs to the 26.3 µF row, so it was mixed up.
• Part number: your PN 416.30.A1.80 does not match the catalog code 416.30.7764. The “A1” and “.80” codes are not defined, so it is probably a special build or alternate coding. Confirm against the label.
• Certifications: the catalog says approvals exclude all 500-550 V models. Don’t list UL, VDE or IMQ.
• Product type: this is a PFC capacitor, not a run capacitor. I removed the “run capacitor” wording.

Ducati Energia 35µF Capacitor, P/N 416.30.A1.80, 550V AC, 3.3 kVAr, 50/60Hz, Double FASTON, Metal Case, Floppy Cap Series, for Mecc Alte Generators

• Capacitance: 35 µF (-5/+10%), continuous duty
• Rated voltage: 550V AC, 3.33 kVAr, 6.1 A, 50/60 Hz
• Dimensions: 60 x 137 mm (D x H)
• Terminals: double FASTON 6.3 x 0.8 mm, IP00
• Case: metal case, self-extinguishing plastic lid (UL-94 V2), overpressure safety device
• Standard: IEC 831-1/2, expected life ≥ 80,000 h

Manufacturer Part Number: 416.30.A1.80 (Ducati Energia, Series 416.30 Floppy Cap, supplied via Mecc Alte)

This Ducati Energia 35 µF single-phase capacitor is rated 550V AC (3.33 kVAr) at 50/60 Hz for continuous duty. It has a metal case with a self-extinguishing plastic lid, eco-friendly resin impregnation, and an overpressure safety device. Terminals are double FASTON 6.3 x 0.8 mm. Discharge resistor not included.

Mounting note: leave at least 20 mm of clearance above the element and use flexible wires so the overpressure device can operate.

Not sure this is the right part for your unit? Send us your generator model number or the µF rating on your current capacitor, and reference P/N 416.30.A1.80.

Not sure this is the right part for your unit? Send us your generator model number or the µF rating printed on your current capacitor, and reference P/N 416.17.27.60 for the fastest lookup.
